HARTIG Setting standard DIN 863-1 125 mm with factory calibration

Name: HARTIG Setting standard DIN 863-1 125 mm with factory calibration
Brand: HARTIG
SKU: 31404013

Brand: HARTIG

Length: 125 mm

Art.-no. 31404013

Manufacturer article no. 4900 125 + KS

All versions

Similar products

Individual prices for customers after login

HARTIG Setting standard DIN 863-1 125 mm with factory calibration

Art.-no. 31404013

Quantity

Price per

Piece

You need more information or have not found your desired product?

Application

For setting outside micrometers.

Execution

Measuring faces made of hardened and aged steel. Flatness < 0.3 μm; measuring faces lapped flat and parallel, parallelism ≤ 1 μm.
Accuracy up to 175 mm according to DIN 863 (js2), from 200 mm exceeding DIN 863
Handle prevents transfer of heat from the hands

Delivery

Including manufacturer’s factory calibration certificate

Product information

HAHN+KOLB Catalogue

Certificates/ Documents


Brand	HARTIG
Manufacturer Part Number	4900 125 + KS
Minimum order quantity	1
Length	125 mm
Diameter	8 mm
Gross Weight	0.070 kg
