NUMERIK JENA Incremental length measuring probe METRO, 30 mm, pneumatic feed, axial cable -

NUMERIK JENA Incremental length measuring probe METRO, 30 mm, pneumatic feed, axial cable - - 1

NUMERIK JENA Incremental length measuring probe METRO, 30 mm, pneumatic feed, axial cable - - 2

NUMERIK JENA Incremental length measuring probe METRO, 30 mm, pneumatic feed, axial cable - - 3

NUMERIK JENA Incremental length measuring probe METRO, 30 mm, pneumatic feed, axial cable - - 4

NUMERIK JENA Incremental length measuring probe METRO, 30 mm, pneumatic feed, axial cable

Name: NUMERIK JENA Incremental length measuring probe METRO, 30 mm, pneumatic feed, axial cable
Brand: NUMERIK JENA
SKU: 39200060

Brand: NUMERIK JENA

Art.-no. 39200060

Manufacturer article no. 1371546-01

All versions

Similar products

Individual prices for customers after login

NUMERIK JENA Incremental length measuring probe METRO, 30 mm, pneumatic feed, axial cable

Art.-no. 39200060

Quantity

Price per

Piece

You need more information or have not found your desired product?

Product information

HAHN+KOLB Catalogue

CAD data (available after login)

Certificates/ Documents

Brand	NUMERIK JENA
Manufacturer Part Number	1371546-01
Minimum order quantity	1
Model	SPECTO
Measuring span of electronic length measuring technology	30 mm
Compatibility length measurement scanner	Sinus 1 Vss
Accuracy (+/-)	1.0 µm
Spindle lift	Automatic due to spring return
Measuring pin adjustment	Compressed air
Cable output direction	Axial
Shank diameter	8 mm
Shaft length	55.3 mm
Cable length	1.5 m
Length x width x height (LxBxH (in Ruhe-Position))	141,2 x 10 x 14 mm
Min./max. operating pressure	1,0-2,5 bar
IP protection class	IP 64, IP 67
Power supply voltage	5 V
Current consumption	110 mA
Connection thread	M2.5
Gross Weight	0.294 kg
